10G SFP+ Transceivers
FiberUnion 10GBASE SFP+ transceivers give you a wide variety of 10 Gigabit Ethernet connectivity options among a wide variety of routers, switches and optical transport equipment. They are compliant with IEEE 802.3ae and SFF-8432 SFP+ MSA standards.
Applications:
* Data Center
* Enterprise Wiring Closet
* Service Provider Transport
| 10G SFP+ | ||||||||
| P/N | Description | Data Rate | Max Link Length | Wavelength | Optical Component | TX Power | RX Sensitivity | Temperature |
| 10GSFP-SR | 10GBASE-SR SFP+ 850nm 300m MMF Duplex LC Transceiver | 10Gbps | 300m | 850nm | 850nm VCSEL | -7.3~-1dBm | < -11.1dBm | 0~70°C |
| 10GSFP-LR | 10GBASE-LR SFP+ 1310nm 10km SMF Duplex LC Transceiver | 10Gbps | 10km | 1310nm | 1310nm DFB | -8.2~0.5dBm | < -14.4dBm | 0~70°C |
| 10GSFP-LRM | 10GBASE-LRM SFP+ 1310nm 2km SMF Duplex LC Transceiver | 10Gbps | 2km | 1310nm | 1310nm FP | -6.5~-0.5dBm | < -8.4dBm | 0~70°C |
| 10GSFP-ER-31 | 10GBASE-ER SFP+ 1310nm 40km SMF Duplex LC Transceiver | 10Gbps | 40km | 1310nm | 1310nm DFB | 0~5dBm | < -16dBm | 0~70°C |
| 10GSFP-ER-55 | 10GBASE-ER SFP+ 1550nm 40km SMF Duplex LC Transceiver | 10Gbps | 40km | 1550nm | EML | -1~4dBm | < -16dBm | 0~70°C |
| 10GSFP-ZR-80 | 10GBASE-ZR SFP+ 1550nm 80km SMF Duplex LC Transceiver | 10Gbps | 80km | 1550nm | EML | 0~4dBm | < -23dBm | 0~70°C |
| 10GSFP-ZR-100 | 10GBASE-ZR SFP+ 1550nm 100km SMF Duplex LC Transceiver | 10Gbps | 100km | 1550nm | EML | 0~5dBm | < - 25dBm | 0~70°C |
| 10GSFP-ZR-120 | 10GBASE-ZR SFP+ 1550nm 120km SMF Duplex LC Transceiver | 10Gbps | 120km | 1550nm | EML | 0~5dBm | < - 25dBm | 0~70°C |
| 10GSFP-T-30 | 10GBASE-T SFP+ Copper RJ-45 30m Copper Transceiver | 10Gbps | 30m | N/A | N/A | N/A | N/A | 0~70°C |
| 10GSFP-T-80 | 10GBASE-T SFP+ Copper RJ-45 80m Copper Transceiver | 10Gbps | 80m | N/A | N/A | N/A | N/A | 0~70°C |
| 10GSFP-BX23-10 | 10GBASE-BX10 BIDI SFP+ 1270nm-TX/1330nm-RX 10km SMF Simplex LC Transceiver | 10Gbps | 10km | 1270nm-TX/1330nm-RX | DFB BiDi | -8.2~0.5dBm | <-14.4dBm | 0~70°C |
| 10GSFP-BX32-10 | 10GBASE-BX10-D BIDI SFP+ 1330nm-TX/1270nm-RX 10km SMF Simplex LC Transceiver | 10Gbps | 10km | 1330nm-TX/1270nm-RX | DFB BiDi | -8.2~0.5dBm | <-14.4dBm | 0~70°C |
| 10GSFP-BX23-20 | 10GBASE-BX10 BIDI SFP+ 1270nm-TX/1330nm-RX 20km SMF Simplex LC Transceiver | 10Gbps | 20km | 1270nm-TX/1330nm-RX | DFB BiDi | -6~3dBm | <-14.4dBm | 0~70°C |
| 10GSFP-BX32-20 | 10GBASE-BX10-D BIDI SFP+ 1330nm-TX/1270nm-RX 20km SMF Simplex LC Transceiver | 10Gbps | 20km | 1330nm-TX/1270nm-RX | DFB BiDi | -6~3dBm | <-14.4dBm | 0~70°C |
| 10GSFP-BX23-40 | 10GBASE-BX10 BIDI SFP+ 1270nm-TX/1330nm-RX 40km SMF Simplex LC Transceiver | 10Gbps | 40km | 1270nm-TX/1330nm-RX | DFB BiDi | 1~5dBm | <-15dBm | 0~70°C |
| 10GSFP-BX32-40 | 10GBASE-BX10-D BIDI SFP+ 1330nm-TX/1270nm-RX 40km SMF Simplex LC Transceiver | 10Gbps | 40km | 1330nm-TX/1270nm-RX | DFB BiDi | 1~5dBm | <-15dBm | 0~70°C |
| 10GSFP-BX45-80 | 10GBASE-BX10 BIDI SFP+ 1490nm-TX/1550nm-RX 80km SMF Simplex LC Transceiver | 10Gbps | 80km | 1490nm-TX/1550nm-RX | DFB BiDi | 0~5dBm | <-21dBm | 0~70°C |
| 10GSFP-BX54-80 | 10GBASE-BX10-D BIDI SFP+ 1550nm-TX/1490nm-RX 80km SMF Simplex LC Transceiver | 10Gbps | 80km | 1550nm-TX/1490nm-RX | DFB BiDi | 0~5dBm | <-21dBm | 0~70°C |
| 10GSFP-BX45-100 | 10GBASE-BX10 BIDI SFP+ 1490nm-TX/1550nm-RX 100km SMF Simplex LC Transceiver | 10Gbps | 100km | 1490nm-TX/1550nm-RX | DFB BiDi | 1~5dBm | <-22dBm | 0~70°C |
| 10GSFP-BX54-100 | 10GBASE-BX10-D BIDI SFP+ 1550nm-TX/1490nm-RX 100km SMF Simplex LC Transceiver | 10Gbps | 100km | 1550nm-TX/1490nm-RX | DFB BiDi | 1~5dBm | <-22dBm | 0~70°C |
| DWDM-SFPP-40-x | 10G DWDM SFP+ 100GHz 40km SMF Duplex LC Transceiver (x= C17 - C61 optional channels) | 10Gbps | 40km | 1528.77nm ~ 1563.86nm | EML DWDM | -1~4dBm | <-16dBm | 0~70°C |
| DWDM-SFPP-80-x | 10G DWDM SFP+ 100GHz 80km SMF Duplex LC Transceiver (x= C17 - C61 optional channels) | 10Gbps | 80km | 1528.77nm ~ 1563.86nm | EML DWDM | 0-4dBm | <-23dBm | 0~70°C |
| DWDM-SFPP-80-T | 10G DWDM SFP+ 50GHz C-band Tunable 80km SMF Duplex LC Transceiver | 10Gbps | 80km | 1528.38~1563.86nm | EML DWDM | -1~3dBm | <-22dBm | 0~70°C |
| CWDM-SFPP-10-x | 10G CWDM SFP+ 10km SMF Duplex LC Transceiver (x= 1270nm ~ 1610nm optional wavelengths) | 10Gbps | 10km | 1270nm ~ 1610nm | DFB CWDM | -8.2~0.5dBm | <-14.4dBm | 0~70°C |
| CWDM-SFPP-20-x | 10G CWDM SFP+ 20km SMF Duplex LC Transceiver (x= 1270nm ~ 1610nm optional wavelengths) | 10Gbps | 20km | 1270nm ~ 1610nm | DFB CWDM | -6~2dBm | <-14.4dBm | 0~70°C |
| CWDM-SFPP-40-x | 10G CWDM SFP+ 40km SMF Duplex LC Transceiver (x= 1270nm ~ 1610nm optional wavelengths) | 10Gbps | 40km | 1270nm ~ 1610nm | DFB CWDM | 0~5dBm | <-16dBm | 0~70°C |
| CWDM-SFPP-80-x | 10G CWDM SFP+ 80km SMF Duplex LC Transceiver (x= 1470nm ~ 1610nm optional wavelengths) | 10Gbps | 80km | 1470nm ~ 1610nm | DFB CWDM | 0~4dBm | <-23dBm | 0~70°C |
