400G QSFP112/QSFP-DD Transceivers
FiberUnion provides 400G QSFP112/QSFP-DD transceivers to meet the increasing demand on the applications for 400G Ethernet, Data Centers and Cloud Networks. This kind of transceivers adopt 8x50G and 4x100G architectures, and they are compliant with the IEEE 802.3bs and OSFP MSA.
Applications:
* Upgrade for Existing Data Center
* Networking Interconnect
* New Mega Data Centers
| 400G QSFP112/QSFP-DD | ||||||||
| P/N | Description | Data Rate | Max Link Length | Wavelength | Optical Component | Connector | Power Consumption | Temperature |
| 400GQSFP-DD-SR4 | 400GBASE-SR4 QSFP-DD PAM4 850nm 100m MPO-12/APC MMF Transceiver | 400Gbps | 100m | 850nm | VCSEL 850nm | MTP/MPO-12 (APC) | ≤8W | 0 to 70°C |
| 400GQSFP-DD-SR8 | 400GBASE-SR8 QSFP-DD PAM4 850nm 100m MPO-16/APC MMF Transceiver | 400Gbps | 100m | 850nm | VCSEL 850nm | MTP/MPO-16 (APC) | ≤10W | 0 to 70°C |
| 400GQSFP-DD-FR4 | 400GBASE-FR4 QSFP-DD PAM4 1310nm 2km DOM Duplex LC SMF Transceiver | 400Gbps | 2km | 1271nm,1291nm, 1311nm,1331nm |
CWDM EML | Duplex LC | ≤ 9W | 0 to 70°C |
| 400GQSFP-DD-FR | 4x100G QSFP-DD FR PAM4 1310nm 2km MPO-12/APC SMF Transceiver | 400Gbps | 2km | 1310nm | 1310nm EML | MTP/MPO-12 (APC) | ≤12W | 0 to 70°C |
| 400GQSFP-DD-DR4 | 400GBASE-DR4 QSFP-DD PAM4 1310nm 500m MPO-12/APC SMF Transceiver | 400Gbps | 500m | 1310nm | 1310nm EML | MTP/MPO-12 (APC) | ≤9W | 0 to 70°C |
| 400GQSFP-DD-LR4 | 400GBASE-LR4 QSFP-DD PAM4 1310nm 10km Duplex LC SMF Transceiver | 400Gbps | 10km | 1271nm,1291nm, 1311nm,1331nm |
CWDM EML | Duplex LC | ≤9W | 0 to 70°C |
| 400GQSFP-DD-LR8 | 400GBASE-LR8 QSFP-DD PAM4 1310nm 10km Duplex LC SMF Transceiver | 400Gbps | 10km | 1310nm | LWDM EML | Duplex LC | ≤10W | 0 to 70°C |
| 400GQSFP-DD-ER8 | 400GBASE-ER8 QSFP-DD PAM4 1310nm 40km Duplex LC SMF Optical Transceiver | 400Gbps | 40km | 1310nm | LWDM EML | Duplex LC | <10W | 0 to 70°C |
| 400GQ-DD-XDR4 | 400GBASE-XDR4 QSFP-DD PAM4 1310nm 2km MPO-12/APC SMF Transceiver | 400Gbps | 2km | 1310nm | 1310nm EML | MTP/MPO-12 (APC) | ≤9W | 0 to 70°C |
| 400GQ-112-XDR4 | QSFP112 400GBASE-XDR4 PAM4 1310nm 2km MPO-12/APC SMF Transceiver | 400Gbps | 2km | 1310nm | 1310nm EML | MTP/MPO-12 (APC) | ≤10W | 0 to 70°C |
| 400GQ-112-LR4 | QSFP112 400GBASE-LR4 PAM4 1310nm 10km Duplex LC SMF Transceiver | 400Gbps | 10km | 1310nm | 1310nm EML | Duplex LC | ≤10W | 0 to 70°C |
| 400GQ-112-FR4 | QSFP112 400GBASE-FR4 PAM4 1310nm 2km Duplex LC SMF Transceiver | 400Gbps | 2km | 1310nm | 1310nm EML | Duplex LC | <10W | 0 to 70°C |
| 400GQ-112-SR4 | QSFP112 400GBASE-SR4 PAM4 850nm 50m MPO-12/APC MMF Transceiver | 400Gbps | 50m | 850nm | 850nm VCSEL | MTP/MPO-12 (APC) | ≤9W | 0 to 70°C |
| 400GQ-112-DR4 | QSFP112 400GBASE-DR4 PAM4 1310nm 500m MPO-12/APC SMF Transceiver | 400Gbps | 500m | 1310nm | 1310nm EML | MTP/MPO-12 (APC) | ≤10W | 0 to 70°C |
